Einscan - H ( Multi Utility - Multi Mode Scanner)

Technical Details

•  Scan Mode                                     Standard Scan                            Body Scan                                                      Face Scan
•  Light Source                                                       White Light, visible                                                              Infrared light, invisible
•  Safety                                                                  LED light (eye-safe)                                                            CLASS I (eye-safe)
•  Scan Accuracy                                                        Up to 0.05mm                                                                       Up to 0.6mm
•  Volumetric Accuracy*                                            0.05+0.1mm/m                                                                                /
•  Scan & Align Speed                                         1,200,000points/s, 20FPS                                                      720,000points/s, 20FPS
•  Align Modes                                                  Markers-, Feature-, Hybrid-and                                                  Feature Alignment

                                                                                               Texture Alignment

•  Camera Frame Rate                                                                                   -----------------55FPS----------------
•  Working Distance                                                                                      -----------------470mm-----------------
•  Depth of Field                                                           200-700mm                                                                 200-1500mm
•  Maximum Scan Range                                               420mm*440mm                                                           780mm*900mm
•  Point distance                                                            0.25mm-3mm                                                               0.5mm-3mm
•  Built-in Color Camera                                                                                 -----------------Yes---------------------
•  Color Scanning                                                                                           -----------------Support-----------------
•  Connection Standard                                                                                  -----------------USB3.0-----------------
•  Output Format                                                                                           ------OBJ, STL, PLY, P3, 3MF-------
•  Dimension                                                                                                  ------108mm*110mm*237mm--------
•  Weight                                                                                                       -----------------703g---------------------
•  Certification                                                                                               ----CE, FCC, ROHS, WEEE, KC-----
•  Recommend Configuration          OS:Win10, 64 bit; Graphics card: NVIDIA GTX1080 and higher; Video memory: ≥4GB; Processor: I7-8700; Memory: ≥32GB
