EinStar Rockit

Technical Details

• Product Model: EinStar Rockit
• Scan Mode:                  |                                          Laser HD                                              |                                    IR Repid                             |
• Light Source:                | 19 + 19 Cossed Laser Lines /7 Blue Laser Parallel Lines    |                                   IR VCSEL                            |
•  Resolution                   |                                          0.05 ~ 10 mm                                      |                                   0.2 ~ 10 mm                      |
• Working Distance:       |                          100 ~ 600 mm/100 ~ 400 mm                        |                                 160 ~ 1400 mm                 |
• Scanning Speed          |                                   2,800,000 points/s                                     |                                1,440,000 points/s              |
• Alignment Mode         |                                   Global Marker/Markers/Features            |  Global Marker/Markers/Features/Texture/Hybrid |
• Minimum Scan Volume |                               5*5*5 mm                                                    |                                    50*50*50 mm                   |
• Camera Resolution    |                                                                            3D: 2MP*2 ; Texture: 5MP                                                                |
• Output Formats          |                                                                            STL; OBJ; PLY; 3MF; ASC                                                                  |
• Max FOV:                    |                                   545 x 620 mm /355 x 425 mm                |                               1170 x 1385 mm                  |
• Laser Class                |                                   Class 2                                                        |                               Class 2                                      |
• Outdoor Scanning Environment |               Below   110,000 Lux                                  |                         Below 70,000 Lux                         |
•  Operation Conditions |                                                                                          -10℃~ 40℃                                                                        |
• Interface & Power Source |                                       USB Type-C; Battery: 5500mA*1 Support 60W-PD3.0 Charger
• Dimensions:                 |                                                           (H*D*W): 130 x 37 x 61 mm/ 5.12 x 1.46 x 2.40 in
• Weight:                         |                                  425g / 0.94 lbs (Batteries included), 353g / 0.78 lbs (Batteries excluded)
• Certifications:             |                                                              CE, FCC, ROHS, WEEE, FDA, SRRC, IP50
•  Recommended System Configuration |     Win11, Professional 22H2 (64-bit); Graphics card: NVIDIA GeForce RTX 3060 Laptop GPU or above; VRAM: 6 GB or above; RAM (Minimum): 32 GB, DDR5 dual-channel; RAM (Recommended): 64 GB or above, DDR5 dual-channel;
• Interface: USB 3.0; Processor: 13th Gen Intel®Core™ i7-13700H or above
